Description
Mobil DTE FM 220 Series are high-performance food grade lubricants designed to provide outstanding equipment protection in demanding industrial paper machine circulating systems, gears and bearings.
They are formulated with select high-quality base oils and a proprietary advanced technology additive system carefully balanced to comply with strict international food standards, whilst protect system components from wear, rust and corrosion. Mobil DTE FM Excel Series are NSF H1 registered lubricants and also comply with Title 21 CFR 178.3570 by the Food and Drug Administration (USA) for lubricants with incidental food contact.
Mobil DTE FM Excel Series provide excellent anti-wear protection for bearing and gears operating under severe conditions helping to minimize downtime in favor of productivity.
They exhibit ultra keep clean performance and excellent thermal and oxidative stability helping systems to run free from deposits, for long time, even at high temperatures.
Mobil DTE FM Excel Series oils are formulated to provide maximum protection and lubrication in presence of water.
Their outstanding demulsibility and filterability assure excellent performance and the ability to retain effective filtration even at very fine filtration levels. They readily separate water and retain their characteristics for extended periods of operation.
These fluids permit the use of high steam pressures, temperatures and machine speeds common in high output paper machines.
Mobil DTE FM Excel Series will not contribute to MOAH content in food when used in accordance with FDA 21CFR178.3570 limitations.
Features and Benefits
Mobil DTE™ FM Excel oils balanced formulation has documented high performance in modern high-output paper machine lubrication. Their excellent performance properties in the areas of wear protection, enhanced oxidation stability, chemical stability, effective rust and corrosion protection, and filterability help to extend maintenance service intervals. This results in less required maintenance, longer equipment life and increased production capacity all in good balance with the food grade requirements.
| Features | Advantages and Potential Benefits |
| NSF H1 registered lubricants | Allows use in food and beverage packaging and processing applications |
| Exceptional Wear Protection | Improved bearing and gear performance |
| Outstanding Oxidation and Thermal Stability | Longer oil life
Lower filter replacement costs Cleaner systems Reduced system deposits |
| Effective Water Separation Properties | Allows easier removal of water
Reduces formation of emulsions in systems |
| Excellent Filterability | Keeps oil lines and flow control mechanisms free of deposits
Improved oil flow and cooling performance Lowers filter replacement costs |
| High Level Rust and Corrosion Protection | Protects gears and bearings in wet environments
Provides protection against corrosion in a wet and humid environment |
Applications
Mobil DTE™ FM Excel lubricants are designed to meet the demanding operating conditions in the paper industry whilst complying with the strict requirements of the food industry.
• Paper mill wet end: forming and pressing section.
• Paper mill dry end: drying section, size press, calendar stack, reel, winder.
• Food production and food packaging industrial machinery.
• General purpose lubrication for bearings, gears and hydraulic systems.
Specifications and Approvals
| This product is recommended for use in applications requiring: | 150 | 220 |
| Valmet Paper RAU4L00659_06: OIL RECOMMENDATIONS FOR PAPER AND BOARD MACHINE OIL LUBRICATION SYSTEMS | X | X |
| Valmet Paper RAUAH02724_02_EN_V: MINERAL OIL RECOMMENDATIONS FOR ZONE-CONTROLLED ROLLS | X | X |
| Voith Paper VS 108 5.3.1 2023-04 (wet end) | X | |
| Voith Paper VS 108 5.3.2 2023-04 (dry end) | X | |
| Voith Paper VS 108 5.3.3 2023-04 (off-line coaters) | X | |
| Voith Paper VS 108 5.3.4 2023-04 (hydraulic roll) | X | |
| Voith Paper VS 108 5.3.5 2023-04 (shoe press) | X | X |
| Voith Paper VS 108 5.3.6 2023-04 (winder) | X |
| This product is registered to the requirements of: | 150 | 220 |
| NSF H1 | X | X |
| This product meets or exceeds the requirements of: | 150 | 220 |
| DIN 51517-3:2018-09 | X | X |
| DIN 51524-2:2017-06 | X |
Properties and Specifications
| Property | 150 | 220 |
| Grade | ISO VG 150 | ISO VG 220 |
| Air Release Time, 75 C, min, ASTM D3427 | 16.1 | |
| Air Release, 75 C, min, ASTM D3427 | 10.9 | |
| Copper Strip Corrosion, 3 h, 100 C, Rating, ASTM D130 | 1B | 1A |
| Demulsibility, Time to 3 mL Emulsion, 82 C, min, ASTM D1401 | 15 | 10 |
| Density @ 15 C, kg/l, ASTM D4052 | 0.8812 | 0.8814 |
| FZG Scuffing, Fail Load Stage, A/8.3/90, ISO 14635-1 | 12+ | 14+ |
| Flash Point, Cleveland Open Cup, °C, ASTM D92 | 238 | 202 |
| Foam, Sequence I, Stability, ml, ASTM D892 | 0 | 0 |
| Foam, Sequence I, Tendency, ml, ASTM D892 | 0 | 0 |
| Foam, Sequence II, Stability, ml, ASTM D892 | 0 | 0 |
| Foam, Sequence II, Tendency, ml, ASTM D892 | 0 | 40 |
| Foam, Sequence III, Stability, ml, ASTM D892 | 0 | 0 |
| Foam, Sequence III, Tendency, ml, ASTM D892 | 0 | 0 |
| Kinematic Viscosity @ 40 C, mm2/s, ASTM D445 | 150 | 210.8 |
| Pour Point, °C, ASTM D97 | -18 | -15 |
| Rust Characteristics, Procedure A, ASTM D665 | Pass | |
| Rust Characteristics, Procedure B, ASTM D665 | Pass | Pass |
Download TDS (Technical Data Sheet)
Click here to download the Technical Data Sheet
Health and safety
If you need MSDS for this item, please contact us.
